Universal User Interface

ASM Debugger

  • Supports almost all file formats
  • Assembler source-level debugging
  • Advanced memory display
  • Inline assembler
  • Memory tests
  • Customizable windows
  • Peripheral windows
  • Terminal window
  • Semi-hosting
  • Flash programming
  • Full support for peripherals
ASM Debugger

High-Level-Language Debugging

  • Supports multiple languages
  • Full support for C++
  • Integrated into TRACE32® environment
  • Supports most compilers and hosts
  • Same user interface on different hosts
  • High speed download
  • Debugs optimized code
  • Display of function nesting
  • Display of linked lists
  • Powerful expression evaluation

TRACE32® Instruction Set Simulators

  • Integral part of TRACE32®
  • Configurable as system under debug (PBI=SIM)
  • Allows post-mortem debugging
  • Software compatible to all TRACE32® tools
  • OS-aware debugging
  • Cache simulation (architecture dependent)
  • Program and data flow trace based on a bus trace protocol
  • Advanced trace analysis features
  • Powerful script language
  • Programming interface for peripheral simulation
  • Not available for processor architectures that support user-defined instructions
TRACE32 Instruction Set Simulators

TRACE32® Front-End

  • Front-end to third-party virtual targets
  • Front-end to third-party core simulators
  • Front-end to third-party target servers
  • Front-end to TRACE32® Back-End
  • Same GUI as TRACE32® hardware debuggers
  • Debug features as provided by third-party software/TRACE32® Back-End
  • Trace features as provided by third-party software/TRACE32® Back-End
  • Windows, Linux and MacOSX
  • Reprise RLM floating licenses

ROM Monitor

  • Compatible with Emulator
  • Support for C,C++ and ASM
  • Communication via Eprom Simulator
  • Communication via RS232 or customized .DLL link
  • Windows9x, WindowsNT and Unix
  • Monitor Code with Source
  • Monitor Code Royalty Free
ROM Monitor

Logical Display of Peripherals

  • Display of onchip peripherals
  • User definable windows
  • Interactive window definition with softkey support
  • Pulldown menues for selection of choices
  • Additional description for each field

Script Language PRACTICE

  • Structured Language
  • Menu Support
  • Command Logs
  • Custom Menues
  • Custom Toolbars and Buttons
  • Custom Dialog Windows
  • 64-Bit Arithmetic
  • Numeric, Logical and String Operators
  • Direct Access to System States
Script Language PRACTICE

Trace-based Debugging (CTS)

  • Allows re-debuggging of a traced program section
  • Provides forward and backward debugging capabilities
  • High-level language trace display including all local variables
  • Timing and function nesting display
  • Has the ability to fill most trace gaps caused by the limited bandwidth of trace port

Logger

  • Software trace of any size stored in an array structure on the target
  • General trace format provided by TRACE32®-PowerView
  • Configuration and display commands provided by TRACE32®-PowerView
  • Works as trace with address and data information
  • Works as a program flow trace (SH4, PowerPC)
  • Time stamp possible
  • Predefined algorithms to fill the trace provided by Lauterbach
  • User defined algorithms to fill the trace also possible
Logger

Snooper

  • Samples memory while application is running
  • Support for special debug communication channels
  • All trace display and analysis functions can be used
  • Trigger on specific values
  • Dynamic performance analysis

Trace-based Profiling

  • Detailed analysis of function run-times
  • Detailed analysis of task run-times and state
  • Graphical analysis of variable values over the time
  • Analysis of the time interval of a single event (e.g. Interrupt)
  • Analysis of the time interval between 2 defined events
Trace-based Profiling

Sample-based Profiling

  • Long-time performance analysis for functions
  • Long-time performance analysis for tasks
  • Long-time analysis of the contents of a variable or memory location and more

Trace-based Code Coverage

  • Real-time code coverage without instrumentation
  • Suitable for long-term testing
  • Support for all common code coverage metrics
  • Automated report generation
  • Full support of multicore chips
Trace-based Code Coverage

Memory Analysis

  • Display of allocated memory blocks
  • Memory allocation Statistics
  • Check for out-of-bounds writes
  • Trace of allocation calls
  • Graphical displays of memory usage

FLASH Programming (Memory-Mapped)

  • Optimum flash programming performance
  • Support for all file formats
  • Ready-to-run flash scripts
  • Ready-to-use flash programming algorithms
  • Dialog- or command-based programming as well as full scripting
  • Full awareness of sensitive data
  • Flash declaration via CFI
  • Easy handling of different flash types on a target
  • Software breakpoints in flash
  • Simple code patching in flash
  • Flash programming via boundary scan
FLASH Programming (Memory-Mapped)

FLASH Programming (Protocol-Based)

  • Optimum flash programming performance
  • Support for elf, Intel hex and S-record format
  • Ready-to-use flash programming scripts
  • Ready-to-use flash programming algorithms
  • Memory dump for displaying the flash content
  • Flash content can be easily copied and modified
  • Flash programming via boundary scan (SPI, eMMC, I2C)
  • Full programming access to spare area (NAND)
  • Bad block treatment (NAND)
  • ECC generation: Hamming, BCH, Reed-Solomon (NAND)

Multicore Debugging

  • Debugger for all cores of a multicore chip
  • Debugging of application cores, DSPs, accelerator cores and special-purpose cores
  • Debugging of more than 80 core architectures
  • Support for every multicore topology
  • Support for all multicore operation modes
  • Support for AMP and SMP systems
  • Single debug hardware can be licensed for all cores of a multicore chip
Multicore Debugging
Multicore Debugging

TPU Debugger (68332, MPC55x/56x)

  • Full support of TPU1, TPU2 and TPU3
  • Step and Go commands
  • Supports all TPU Breakpoints
  • Disassembler for Microinstructions
  • Monitor all TPU Registers during stepping
  • Modify TPU internal Registers
  • Display of Entry Points
  • Peripheral View of TPU Registers

OS-aware Debugging

  • Real-time, non-intrusive display of RTOS system resources
  • Task stack coverage
  • Task related breakpoints
  • Task context display
  • SMP support
  • Task related performance measurement
  • Statistic evaluation and graphic display of task run times
  • Task related evaluation of function run times
  • PRACTICE functions for OS data
  • Easy access via RTOS specific pull-down menus
  • Support for all major RTOSes
OS-aware Debugging

3rd Party Tool Integration

  • Editor Integration
  • CASE Tool Integration
  • Kernel Integration

Remote Control

TRACE32® Remote API

The TRACE32® Remote API enables Lauterbach customers to control TRACE32® and access the device under test from another program. Typical use cases are:

  • Integration of TRACE32® into an automated production environment
  • Using TRACE32® as an interface to the device under test for test and measurement systems
  • Using TRACE32® as an interface to the device under test for third party tools
Remote Control

The TRACE32® Remote API can be used to control several TRACE32® PowerView instances simultaneously. This is possible by establishing one socket stream per PowerView instance. It does not matter whether the device under test is a physical or virtual target or an instruction set simulator.
